Preview releases with pull requests

This recipe always keeps an open pull request which previews the changes that Knope will include in the next release. This pull request will let you see the next version, the changes to versioned files, and the changelog. When you merge that pull request, Knope will create a new release with the changes from the pull request.

This recipe requires a custom knope.toml file and two GitHub Actions workflows.

knope.toml

Each section below is separate for easier explanation, but all these TOML snippets exist in the same file.

[package]

[package]
versioned_files = ["Cargo.toml", "Cargo.lock"]
changelog = "CHANGELOG.md"
assets = "artifacts/*"

This first piece defines the package. versioned_files are how Knope determines the current package version, and where it puts the new one. Knope will describe the changes in the changelog file in addition to GitHub releases. Knope will expand the assets glob and upload any matching files to the GitHub release. You can also specify assets individually.

prepare-release workflow

Caution

You can’t use this recipe as-is with multiple packages due to limitations on variables. You’ll either need to change any references to those variables or use the workflow dispatch recipe.

[[workflows]]
name = "prepare-release"

[[workflows.steps]]
type = "Command"
command = "git switch -c release"

[[workflows.steps]]
type = "PrepareRelease"

[[workflows.steps]]
type = "Command"
command = "git commit -m \"chore: prepare release $version\""

[[workflows.steps]]
type = "Command"
command = "git push --force --set-upstream origin release"

[workflows.steps.variables]
"$version" = "Version"

[[workflows.steps]]
type = "CreatePullRequest"
base = "main"

[workflows.steps.title]
template = "chore: prepare release $version"
variables = { "$version" = "Version" }

[workflows.steps.body]
template = "This PR was created by Knope. Merging it will create a new release\n\n$changelog"
variables = { "$changelog" = "ChangelogEntry" }

The first workflow has a name of prepare-release, so knope prepare-release will execute it (the GitHub Actions workflow will contain this command). First, it creates a new branch from the current one called release. Next, it runs the PrepareRelease step, which updates the package based on the changes made since the last release. It also stages all those changes with Git (like git add).

Next, the workflow commits the changes that PrepareRelease made—things like:

• Updating the version in Cargo.toml and Cargo.lock
• Adding a new section to CHANGELOG.md with the latest release notes
• Deleting any changesets

The workflow then pushes the commit to the release branch, using the --force flag in this case because the history of that branch isn’t important.

Tip

You could use a variable to name the branch based on the version instead of erasing earlier versions.

The CreatePullRequest step then creates a pull request from the current branch (release) to the specified base branch (main). It uses string templates containing variables to set the title and body, in this case, the title includes the new Version and the body includes the new ChangelogEntry.

The pull request that this creates looks something like this:

release workflow

[[workflows]]
name = "release"

[[workflows.steps]]
type = "Release"

The release workflow is a single Release step—this creates a GitHub release for the latest version (if it doesn’t already exist) and uploads any assets. In this case, it’ll create a release for whatever the prepare-release workflow prepared earlier. GitHub Actions will run this workflow whenever someone merges the pull request (created by prepare-release).

[github]

The last piece is to tell Knope which GitHub repo to use for creating pull requests and releases. You must substitute your own values here:

[github]
owner = "knope-dev"
repo = "knope"

prepare_release.yaml

There are two GitHub Actions workflows for this recipe—the first one goes in .github/workflows/prepare_release.yaml and it creates a fresh release preview pull request on every push to the main branch:

.github/workflows/prepare_release.yaml

on:
  push:
    branches: [main]
name: Create Release PR
jobs:
  prepare-release:
    if: "!contains(github.event.head_commit.message, 'chore: prepare release')" # Skip merges from releases
    runs-on: ubuntu-latest
    steps:
      - uses: actions/[email protected]
        with:
          fetch-depth: 0
          token: ${{ secrets.PAT }}
      - name: Configure Git
        run: |
          git config --global user.name GitHub Actions
          git config user.email [email protected]
      - uses: knope-dev/[email protected]
        with:
          version: 0.18.0
      - run: knope prepare-release --verbose
        env:
          GITHUB_TOKEN: ${{ secrets.PAT }}
        continue-on-error: true

Caution

This workflow runs by default on every push to main, that includes when a release PR merges! There is an if: clause here in the first job that skips it if the commit message looks like the ones create by the prepare-release workflow. If you change that message, you’ll need to update this if: clause as well.

The steps here:

1. Check out the entire history of the repo (so that PrepareRelease can use tags and conventional commits to pick the next version). This requires a personal access token with permission to read the contents of the repo.
2. Configure Git so that the job can commit changes (within Knope’s prepare-release workflow)
3. Install Knope
4. Run the prepare-release workflow described earlier. This requires a personal access token with permission to write the pull requests of the repo.

Note

The continue-on-error attribute means even if this step fails, the workflow will pass. This is because the workflow runs on every push to main, but shouldn’t fail when there’s nothing to release. However, the workflow also won’t fail if there are real errors from Knope. You may want to instead use the allow_empty option in knope.toml and split the rest of the steps into a second workflow. Then, you can use some scripting in GitHub Actions to skip the rest of the workflow if there’s nothing to release.

In this example, the same personal access token is in both steps, but you could use separate ones if you wanted to.

release.yaml

Now that Knope is creating pull requests every push to main, it needs to automatically release those changes when a pull request merges. This is the job of the release workflow, which goes in .github/workflows/release.yaml.

Caution

YAML is sensitive to space and easy to mess up copy/pasting—so you should copy the whole file at the end, not the individual pieces.

To start off, this workflow must only run when release preview pull requests merge—there are several pieces of config that handle this. First:

./github/workflows/release.yaml

on:
  pull_request:
    types: [closed]
    branches: [main]

Will cause GitHub Actions to only trigger the workflow when a pull request which targets main closes. Then, in the first job, an if narrows that down further to only release preview pull requests, and only when they merge (not close for other reasons):

if: github.head_ref == 'release' && github.event.pull_request.merged == true

If you have assets to upload, you’ll want a build-artifacts job which runs before the next step. Skipping on past that job (since it probably will be different for you), the next one is the release job:

release:
  needs: [build-artifacts]
  runs-on: ubuntu-latest
  steps:
    - uses: actions/[email protected]
    - uses: actions/[email protected]
      with:
        path: artifacts
        merge-multiple: true
    - uses: knope-dev/[email protected]
      with:
        version: 0.18.0
    - run: knope release
      env:
        GITHUB_TOKEN: ${{ secrets.PAT }}

The release job follows these steps:

1. Check out the repo at the commit that the pull request merged
2. Download the artifacts from the build-artifacts job
3. Install Knope
4. Run the release workflow described earlier. This requires a personal access token with permission to write the contents of the repo.

Finally, our example workflow publishes to crates.io—meaning the whole workflow looks like this:

name: Release

on:
  pull_request:
    types: [closed]
    branches: [main]

jobs:
  build-artifacts:
    if: github.head_ref == 'release' && github.event.pull_request.merged == true
    strategy:
      fail-fast: false
      matrix:
        include:
          - target: x86_64-unknown-linux-musl
            os: ubuntu-latest
          - target: x86_64-apple-darwin
            os: macos-latest
          - target: aarch64-apple-darwin
            os: macos-latest
          - target: x86_64-pc-windows-msvc
            os: windows-latest
    env:
      package_name: # TODO: Replace with your package name

    runs-on: ${{ matrix.os }}
    name: ${{ matrix.target }}

    steps:
      - uses: actions/[email protected]
      - uses: Swatinem/[email protected]
      - name: Install host target
        run: rustup target add ${{ matrix.target }}

      - name: Install musl-tools
        if: ${{ matrix.target == 'x86_64-unknown-linux-musl' }}
        run: sudo apt-get install -y musl-tools

      - name: Build
        run: cargo build --release --target ${{ matrix.target }}

      - name: Set Archive Name (Non-Windows)
        id: archive
        run: echo "archive_name=${{ env.package_name }}-${{ matrix.target }}" >> $GITHUB_ENV

      - name: Set Archive Name (Windows)
        if: ${{ matrix.os == 'windows-latest' }}
        run: echo "archive_name=${{ env.package_name }}-${{ matrix.target }}" | Out-File -FilePath $Env:GITHUB_ENV -Encoding utf8 -Append

      - name: Create Archive Folder
        run: mkdir ${{ env.archive_name }}

      - name: Copy Unix Artifact
        if: ${{ matrix.os != 'windows-latest' }}
        run: cp target/${{ matrix.target }}/release/${{ env.package_name }} ${{ env.archive_name }}

      - name: Upload Artifact
        uses: actions/[email protected]
        with:
          name: ${{ matrix.target }}
          path: ${{ env.archive_name }}.tgz
          if-no-files-found: error

  release:
    needs: [build-artifacts]
    runs-on: ubuntu-latest
    steps:
      - uses: actions/[email protected]
      - uses: actions/[email protected]
        with:
          path: artifacts
          merge-multiple: true
      - uses: knope-dev/[email protected]
        with:
          version: 0.18.0
      - run: knope release
        env:
          GITHUB_TOKEN: ${{ secrets.PAT }}

  publish-crate:
    needs: [release]
    runs-on: ubuntu-latest
    steps:
      - uses: actions/[email protected]
      - uses: Swatinem/[email protected]
      - uses: katyo/publish-crates@v2
        with:
          registry-token: ${{ secrets.CARGO_TOKEN }}

Tip

Use Renovate to keep those versions of Knope up to date.

Conclusion

Just to summarize, this recipe describes a process that:

1. Automatically creates a pull request in GitHub every time a new commit is pushed to main. That pull request contains a preview of the next release.
2. Automatically releases the package every time a release preview’s pull request is merged.
